Product Details:
| Packaging Size | 40 Kgs |
| Grade Standard | Zone-II |
| Packaging Type | Non Woven Bag |
| Bulk Density | 1.56 g/cm3 |
| Purity | 98.9 % |
| Particle Size | +0.600 microns -3.5 mm |
Bags Packing & Loading Charges Extra.
Strength Comparison for Mortar Mix:
| Compressive Strength (N/mm2) (28 Days) (Average 3 Samples) | |
| Ordinary Sand | Silica Sand |
| 39.9 | 44.8 |
Particle Size Silica Sand :
| I.S. 2386: Part – 1, Clause 2.0 | ||||||
| Sieve Size | % Passing | % passing (As per 1.S. 383 – 2016, Table-09) Clause 63 | % passing IS 1542:1992 ( 2003 Revised) Clause 5.1 ,2M1Rcm.) 6.-5, |
|||
| Grading | ||||||
| Zone I | Zone II | Zone III | Zone IV | Grading | ||
| 10 mm | 100.0 | 100 | 100 | 100 | 100 | 100 |
| 4.75 mm | 100.0 | 90-100 | 90-100 | 90-100 | 95-100 | 95-100 |
| 2.36 mm | 100. | 60-95 | 75-100 | 85-100 | 95-100 | 95-100 |
| 1.18 mm | 95. | 30-70 | 55-90 | 75-100 | 95-100 | 90-100 |
| 600 micron | 83. | 15-34 | 35-59 | 60-79 | 80-100 | 80-100 |
| 300 micron | 47. | 5-20 | 8-80 | 12-40 | 15-50 | 20-65 |
| 150 micron | 6. | 0-10 | 0-10 | 0-10 | 0-15 | 0-15 |
Additional Information:
- Packaging Details: Bags Packing & Loading Charges Extra.
